10 Micron Water Filteration Metal Filter Cartridges Stainless Steel Cartridge
Metal Filter Cartridges Stainless Steel Cartridge Descriptions:
The sintered filter is made of stainless steel power ,through the sub-screen, forming, sintering to micro-filter components. According to user requirements can produce a variety of shapes, structure, different size, porosity of porous components, such as: hood, cap, sheet, tube, rod-like filter element.
Standrad Sintered Mesh consists five layers:the protctive layer,the filter layer, the dispersion layer, two reinforcing meshes.Owing to its surface filtration construction,and smooth wire of the mesh,it is good at backwashing andregeneration. Futhermore,this mesh is easy to be formed,machined and welded. It can be produced into many kinds of shapes such as circular,cartridge,cone and pleats.
Metal Filter Cartridges Stainless Steel Cartridge Characteristics:
| Materials | SS316L, 904L,Monel,Inconel, Alloy20, Duplex |
| Features | Easy cleaning, especially bak washing owing to the surface.Good permeability
High mechanical strength , excellent resistance to pressure ang high mechanical strength due to the fourth and fifth layers reinforced.
good corrosion resistance
Durable at work
No immigration of materials.
Heat resistant up to 350℃ |
| Application | Polyester oil products
chemical industrial products
pharmaceutics
water and gas
food and beverage.
|
Metal Filter Cartridges Stainless Steel Cartridge Main Connection Type
*Standard interface, such as 222, 220, 226
*Fast interface
*Flange connection
*Tie rod connection
*Threaded connection
*Customized connection
Metal Filter Cartridges Stainless Steel Cartridge Advantages:
1).high flow, high precision
2).high porosity, permeability, pressure drop very low
3). excellent mechanical strength, resistance to high pressure up to 200Kg
4).easy to clean, backpulsing
5).corrosion resistance, high temperature resistance
6) .good processing performance, folding, welding, adhesive
7).design flexibility
8).80-200l/min - rated flow; working pressure 1.5-2.5pa; filtering area (M2) 0.01-3.0; (m) 2-200. filtering accuracy
